Диаметр каната (мм) |
Индекс нагрузки kg/100m |
Индекс нагрузки на разрыв (kN)(Min B/L) |
||
|
1320/1770N/mm2 |
1570N/mm2 |
1770N/mm2 |
||
|
( Doubel T/S ) |
( Single T/S ) |
( Single T/S ) |
||
|
|
|
|
|
|
|
8 |
22.2 |
28.1 |
29.4 |
33.2 |
|
|
|
|
|
|
|
9 |
28.1 |
35.6 |
37.3 |
42.0 |
|
|
|
|
|
|
|
9.5 |
31.3 |
39.7 |
41.5 |
46.8 |
|
|
|
|
|
|
|
10 |
34.7 |
44.0 |
46.0 |
51.9 |
|
|
|
|
|
|
|
11 |
42.0 |
53.2 |
55.6 |
62.8 |
|
|
|
|
|
|
|
12 |
50.0 |
63.3 |
66.2 |
74.7 |
|
|
|
|
|
|
|
12.7 |
56.0 |
70.9 |
74.2 |
83.6 |
|
|
|
|
|
|
|
13 |
58.6 |
74.3 |
77.7 |
87.6 |
|
|
|
|
|
|
|
14 |
67.9 |
86.1 |
90.2 |
102.0 |
|
|
|
|
|
|
|
16 |
88.8 |
113.0 |
118.0 |
133.0 |
|
|
|
|
|
|
|
19 |
125.0 |
159.0 |
166.0 |
187.0 |
|
|
|
|
|
|
|
22 |
168.0 |
213.0 |
223.0 |
251.0 |
